It is used in the test laboratories of factories producing industrial electrical devices or companies producing motors.

With Adjustable Current source, switch, fuse, contactor etc. The current carrying capacity of electrical products is tested. Adjustable current sources can be produced between 1,000A and 15,000A.

They can be produced with Variac and thyristor control upon request. While the output voltage change in thyristor-controlled test devices is around 3V, the voltage change in variac-controlled ones is around 5V. Optionally, production is made for a lower voltage level (0.1 VAC).

Adjustable constant current welding machines are controlled with 0-10VDC or 4-20 mA. Changes in the set current value are stabilized with the help of the microprocessor control card.

An isolation transformer can be used for safety purposes during testing.

Since it has a very wide spectrum, needs are determined through interviews with the customer. Circuit diagrams, assembly diagrams and operating principles are reported and shared with the user. Production starts upon approval.

It has the possibility of adjusting the output voltage by button, PLC and PC.

Optional Features

➤ Isolated transformer preference
➤ Leakage current protection,
➤ Emergency button
➤ Current or voltage adjustment option
➤ Voltage selection preference between 0-600V
➤ 0-10 VDC, 4-20 mA, adjustment by potentiometer or button.
➤ Voltmeter option (Digital or analog)
➤ TFT panel option
➤ Ammeter option (Digital or analog)

➤ 4×20 LCD option
➤ Constant current source option
➤ Constant voltage option
➤ Remote control option
➤ RS-232 Communication option
➤ Dry contact information
➤ Manual control option
➤ Automatic control option
➤ Microprocessor control option

➤ PLC control option
➤ Button control option
➤ Wheel option
➤ Cooling with fan
➤ Silent operation
➤ Conditions test
➤ IP 20 – IP65 Protection class
➤ CE and ISO-9001 certified
