GENERAL FEATURES

➤ They have a long life depending on the alloy properties of the lead used.
➤ It is delivered to the user with fasteners. Their installation is easy and safe.
➤ It is shipped as wet or dry charged according to customer request.
➤ It is designed to be low-maintenance and does not require the addition of pure water for a long time.

STRUCTURAL FEATURES

Positive Plates: They are tube types. Tergal, consisting of consecutive tubes, is placed on the rods connected to each other at the top, forming the positive grid. These tubes are then tightly filled with the active ingredient.

Negative Plates: Obtained by coating the grids made of high purity lead with the active substance.

Separators: They comply with world standards, have a thin structure, are microporous and facilitate the flow of current.

Cell Boxes: They are transparent, acid and high temperature resistant plastic (SAN TYPE) boxes. Depending on the battery capacity, 2, 6 or 12 volt OPzS series cell boxes are used.

Plugs: They have a structure that allows the release of free gases (H2 and O2) easily and prevents electrolyte leakage.

AREAS OF USE

➤ Telephone Switchboards
➤ Electrical Protection and Switchgear Facilities
➤ Power Plants
➤ Radio – Link Systems
➤ Solar and Wind Energy Systems
➤ Ship Batteries
➤ Signaling Systems
➤ Security Systems
➤ Uninterruptible Power Supplies (UPS)
➤ Alarm Systems
➤ Safety Lightings

OPZS SERIES (2 Volt cells)
Voltage	Capacity	Model	Length	Width	Height	Weight	Weight
(Volt)	(AH)		(mm)	(mm)	(mm)	DRY(Kg)	Acidic(Kg)
2	100	4 OPZS 100	103	206	380	8	13
2	150	4 OPZS 150	103	206	380	10	15
2	200	4 OPZS 200	103	206	380	13	18
2	250	5 OPZS 250	124	206	380	15	21
2	300	6 OPZS 300	145	206	380	19	26
2	350	7 OPZS 350	124	206	496	21	28
2	420	6 OPZS 420	145	206	496	24	33
2	490	7 OPZS 490	166	206	496	28	39
2	600	6 OPZS 600	145	206	671	33	46
2	800	8 OPZS 800	191	210	671	47	65
2	1000	10 OPZS 1000	233	210	671	58	79
2	1200	12 OPZS 1200	275	210	671	67	92
2	1500	12 OPZS 1500	275	210	821	82	116
2	2000	16 OPZS 2000	397	212	797	110	155
2	2500	20 OPZS 2500	487	212	797	135	200
2	3000	24 OPZS 3000	576	212	797	160	230

OPZS SERIES (6&12 Monoblock Batteries)
VOLTAGE	CAPACITY	MODEL	LENGTH	WIDTH	HEIGHT	WEIGHT	WEIGHT
(VOLT)	(AH)		(mm)	(mm)	(mm)	DRY(Kg)	ACIDIC(Kg)
6	100	4 OPZS 100	272	205	380	36	49
6	150	4 OPZS 150	272	205	380	41	52
6	200	4 OPZS 200	272	205	380	48	61
12	50	2 OPZS 50	272	165	285	30	36
12	100	2 OPZS 100	272	205	363	38	50
12	150	3 OPZS 150	380	205	363	55	70
